How to Install Your New Nova Chair | OfficeLogixShop Setup Guide
Welcome to the step-by-step unboxing and installation guide for the Nova Chair by OfficeLogixShop. This tutorial will help you quickly assemble your ergonomic chair for optimal comfort and performance.
1. What’s Inside the Box
- Arms labeled L (Left) and R (Right)
- Chair mechanism
- Chair base
- Seat with manual
- Back rest
- Casters and cylinder (inside a small box)
- Bolts and assembly tools
Note: Keep the packaging materials in case a return is necessary. Returns must be sent in the original box.
2. Installing the Casters
- Flip the base upside down
- Firmly press each caster into its slot until it clicks into place
3. Attaching the Arms
- Turn the seat upside down
- Identify the arms labeled L and R
- Match each arm to the opposite side (since you’re looking at the back of the seat)
- The smooth, sloped edge of the seat indicates the front
- Use the screws with the smaller diameter washers
- Insert the top screw loosely to align the arm
- Insert the remaining screws and then tighten all of them
- Repeat for the second arm
4. Installing the Mechanism
- Place the mechanism into the cavity at the back of the seat
- Ensure the round hole faces the back and the levers face the front
- Align the holes and insert the screws
- Tighten them in a diagonal pattern for best stability
5. Attaching the Back Rest
- Slightly loosen the two bolts on the back rest
- Stand the seat upright with the mechanism facing up
- Slide the metal plate of the back rest under the mechanism
- Let the washers rest on top of the mechanism and tighten the bolts
- Insert the thick center bolt with the small washer into the middle hole
- If needed, gently wiggle to fit
- Tighten the center bolt just enough to hold it
- Insert and tighten the short bolts on both sides
- Finish by tightening the center bolt fully
6. Final Assembly
- Insert the cylinder into the center of the mechanism
- Your Nova Chair is now fully assembled and ready to use
Frequently Asked Questions
What should I do with the packaging materials after unboxing my Nova Chair?
You must keep all the packaging materials just in case a return is necessary because returns must be sent securely in the original box.
How do I properly identify the front of the seat when attaching the arms?
When you turn the seat upside down you will easily notice that the smooth sloped edge of the seat indicates the front.
Which specific screws do I need to use to attach the chair arms?
You must securely use the specific screws that come completely equipped with the smaller diameter washers to attach both arms.
What is the correct direction to position the mechanism before tightening?
When placing the mechanism into the cavity at the back of the seat you must ensure the round hole faces the back and the levers face the front then tighten the screws in a diagonal pattern for best stability.
Thank You
Thank you for choosing the Nova Chair from OfficeLogixShop. If you have any questions or need help with another product, our team is here to support you.
