How to Install the Haworth Zody Headrest
Welcome to this official OfficeLogixShop Haworth Zody Headrest installation guide. This tutorial walks you through each step to complete the setup and enhance your Zody chair with professional ergonomic neck support.
1. Disassemble the Bracket
- Locate the two screws on the inner side of the headrest spine.
- Remove both screws using a Phillips screwdriver to release the bracket.
2. Position the Headrest
- Center the headrest at the top of the chair, directly above the Haworth logo.
- Make sure it is straight before proceeding.
3. Install the Bracket
- Align the bracket with the dedicated rails on the headrest spine.
- Push the bracket upward until it is fully seated in place.
4. Secure the First Screw
- Insert the first screw into the bracket.
- Tighten it with the screwdriver until it is firmly in place.
5. Secure the Second Screw
- Insert the second screw and tighten it the same way.
- Make sure both screws are fully secured before moving on.
6. Adjust the Forward and Backward Position
- Push the headrest all the way forward to unlock the movement.
- Then move it backward to your preferred position.
- This serves as the lock, holding it in place when you rest your head on it.
7. Adjust the Height
- Press the button on the side of the headrest to move it up or down.
- Slide the bracket as needed to set the overall height.
8. Tilt the Cushion
- Tilt the headrest cushion upward for added comfort if desired.
Frequently Asked Questions
What tool do I need to remove the bracket screws on the Haworth Zody headrest?
You will need a Phillips screwdriver to remove both screws located on the inner side of the headrest spine to successfully release the bracket.
Where exactly should I position the OfficeLogixShop headrest before installing the bracket?
You should center the headrest at the top of the Haworth Zody chair directly above the Haworth logo and make sure it is perfectly straight before proceeding.
How do I adjust and lock the forward and backward position of my new headrest?
You push the headrest all the way forward to unlock the movement then move it backward to your preferred position. This action serves as the lock holding it safely in place when you rest your head on it.
How can I change the vertical height of the Haworth Zody chair headrest?
You simply press the button on the side of the headrest to smoothly move it up or down and slide the bracket as needed to perfectly set the overall height.
9. Final Check
- Make sure the headrest is secure, comfortable, and adjusted to your liking.
- Your Haworth Zody headrest is now installed and ready to use.
Tip: Adjust the headrest height and angle until you find the most comfortable position for your neck and head.
